NL6448BC33-46

matrix color liquid crystal display, thin film transistor, –0.3 to 6.5 V, Low reflection, 10.4"screen, 640 x 480pixels, 262,144 colors

Rated 5 Rating 5 | reviews | Write a review

Price:: US $73.50~83.50 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $73.50~83.50

PartNumber:: NL6448BC33-46

Brand:: NEC - Nec | Pack: DIP | D/C: 04+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Mr. Juven You's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-12-14

From Other Seller

Part Number:NL6448BC33-46
US $73.50 - 83.50
AT45DB161B-TI

US $0.90 - 2.00 / Piece
(0) Remove
AT45DB161B-TU

US $1.00 - 2.00 / Piece
(0) Remove
Quantity:

piece

Product Summary

The NL6448BC33-46 is a TFT (thin film transistor) active matrix color liquid crystal display (LCD) comprising amorphous silicon TFT attached to each signal electrode, a driving circuit and a backlight. It has a built-in backlight. Backlight includes long-life-lamps and the lamps are replaceable. The NL6448BC33-46 is suitable for industrial application use because of the wide viewing angle and the high luminance. The applications of it include: Display terminals for control system, Monitors for process controller, Industrial PCs.

Parametrics

NL6448BC33-46 absolute maximum ratings: (1)Supply voltage VCC: –0.3 to 6.5 V; (2)Input voltage VI: –0.3 to VCC +0.3 V; (3)Lamp voltage VL: 2000 Vrms; (4)Storage temp. TST: –20 to 60 ℃; (5)Operating temp. TOP: 0 to 50 ℃; (6)Humidity(no condensation)RH: ≤ 95% relative humidity(Ta ≤ 40℃); ≤ 85% relative humidity(40 < Ta ≤ 50℃); Absolute humidity shall not exceed Ta = 50℃, 85% relative humidity level(Ta > 50℃).

Features

NL6448BC33-46 features: (1)Wide viewing angle (with Retardation Film); (2)Smooth polarizer surface (No antiglare treatment); (3)High luminance (350 cd/m2, typ.: saturated value, at room temp.); (4)Low reflection; (5)6-bit digital RGB signals; (6)Data enable function; (7)Backlight with two long-life-time lamps (one lamp holder, inverter-less); (8)Lamp holder replaceable; (9)Reversible scan direction (with DPS pin); (10)Replaceable lamp holders; (11)Recommended inverter; (12)Best viewing angle select function (with MVA terminal); (13)Luminance control; (14)Easy to attach a touch panel.
