Product Summary

The SC111715CFGE is a high performance positive voltage regulator. It is desgined for use in applications reguiring low dropout performance at full rated current.

Parametrics

Absolute maximum ratings: (1)input voltage:15V; (2)power dissipation: internally limited; (3)operating temperature range:0℃ to 125℃; (4)storage temperature range:-65℃ to 150℃; (5)lead temperature(soldering) 10sec.:260℃.

Features

Features: (1)Vin 15V max.; (2)low dropout performance, 1.3V max.; (3)full current rating over line and temperature; (4)fast transient response; (5)adjust pin current max 120μA over temperature; (6)fixed/adjustable output voltage; (7)line regulation 0.2% max.; (8)load regulation 0.4% max.

Diagrams
