Product Summary

The A104SN03 is a 10.4 inch color TFT-LCD module.

Parametrics

A104SN03 absolute maximum ratings: (1)power voltage, VDDIO: -0.5 to 5V; AVDD: -0.5 to 15V; VGH: -0.3 to 42V; VGL: -20 to 0.3V; VGH-VGL: 40V; (2)input signal voltage, VI: -0.3 TO VDDIO+0.3V; VCOMin: 0 to 5V; (3)operating, Topa: -10 to 60℃; (4)storage, Tstg: -20 to 70℃.

Features

A104SN03 features: (1)Screen Size: 10.4 inch(Diagonal); (2)Display Resolution: 800RGB(W)x600(H) dot; (3)Overall Dimension: 228.4(W)x175.4(H)x6.2(D) mm; (4)Active Area: 211.2(W)x158.4(H) mm; (5)Pixel Pitch: 0.264(W)x0.264(H) mm; (6)Color Depth: 16.7M Colors; (7)NTSC Ratio: 50%; (8)Display Mode: Normally White; (9)Panel surface Treatment: Anti-Glare, 3H; (10)Weight: 400±20g; (11)Panel Power Consumption: 0.43W; (12)Backlight Power Consumption: 2.97W; (13)Viewing direction: 6 o’clock (gray inversion).

Diagrams

A104SN03 block diagram
